DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

351

To view the following window, click L3 Features > IP Multicast Routing Protocol > IPv6MC > IPv6 Static Multicast

Route Settings, as shown below:

Figure 6-156 IPv6 Static Multicast Route Settings Window

The fields that can be configured are described below:

Parameter Description

IPv6 Address/Prefix Length

Enter the IPv6 network address and prefix length of the multicast source here. A

decimal value that indicates how many of the high-order contiguous bits of the

address comprise the prefix (the network portion of the address). A slash mark

must precede the decimal value.

Interface VLAN

Enter the VLAN ID that will be used here. The range is from 1 to 4094.

RPF Neighbor Address

Enter the IPv6 address of the next hop that can be used to reach the specified

network here. Select the NULL option to specify that the RPF check result will

always fail.

Click the Apply button to accept the changes made.

Click the Clear All button to clear the information displayed.

Click the Delete button to remove the specific entry.

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

IPv6 Multicast Routing Table

This window is used to display the contents of the IPv6 dynamic multicast routing table.

To view the following window, click L3 Features > IP Multicast Routing Protocol > IPv6MC > IPv6 Multicast

Routing Table, as shown below:

Figure 6-157 IPv6 Multicast Routing Table Window
