DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
700
Reboot Schedule
Log Description Severity
Event Description: Tips is about will to reboot switch within the specified time.
Log Message: Display “Reboot scheduled in 5 minutes” when the countdown equals 5
minutes
Warning
Event Description: Tips is about will to reboot switch within the specified time.
Log Message: Display ”Reboot scheduled in 1 minute” when the countdown equals 1
minute
Critical
Event Description: after schedule reboot in a specific interval.
Log Message: System was restarted by schedule in an interval time
Informational
Event Description: after schedule reboot at specific time.
Log Message: System was restarted by schedule at specific time
Informational
Event Description: after schedule reboot happens with save_before_reboot configured.
Log Message: Configuration was saved by schedule
Informational
Safeguard
Log Description Severity
Event Description: When the CPU utilization is over the rising threshold, the switch enters
exhausted mode, and the syslog will be recorded.
Log Message: Unit <unit-id>, Safeguard Engine enters EXHAUSTED mode
Parameters Description:
unit-id: Unit ID.
Warning
Event Description: When the CPU utilization is lower than the falling threshold, the switch
enters normal mode, and the syslog will be recorded.
Log Message: Unit <unit-id>, Safeguard Engine enters NORMAL mode
Parameters Description:
unit-id: Unit ID.
Informational
SD Card Management
Log Description Severity
Event Description: schedule execute configuration failure.
Log Message: Entry <entry-name> to execute configuration <filename> at time <time-
range> failure
Parameters Description:
entry-name: The name for this schedule execute configuration entry.
filename: The filename of the configuration.
time-range: The name of the time range.
Warning
Event Description: schedule backup configuration or log failure.
Log Message: Entry <entry-name> to backup <type>:<filename> at time <time-range>
failure
Parameters Description:
entry-name: The name for this schedule execute configuration entry.
type: Configuration or log.
filename: The filename of the configuration.
time-range: The name of the time range.
Warning
