DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
716
Trap Name Description OID
included value of ifOperStatus.
Binding objects:
(1) ifIndex
(2) ifAdminStatus
(3) ifOperStatus
LBD
Trap Name Description OID
swPortLoopOccurred The trap is sent when a port loop occurs.
Binding objects:
(1) swLoopDetectPortIndex
1.3.6.1.4.1.171
.14.46.0.1
swPortLoopRestart The trap is sent when a port loop restarts after the interval
time.
Binding objects:
(1) swLoopDetectPortIndex
1.3.6.1.4.1.171
.14.46.0.2
swVlanLoopOccurred The trap is sent when a port loop occurs under LBD
VLAN-based mode.
Binding objects:
(1) swLoopDetectPortIndex
(2) swVlanLoopDetectVID
1.3.6.1.4.1.171
.14.46.0.3
swVlanLoopRestart The trap is sent when a port loop restarts under LBD
VLAN-based mode after the interval time.
Binding objects:
(1) swLoopDetectPortIndex
(2) swVlanLoopDetectVID
1.3.6.1.4.1.171
.14.46.0.4
LDP
Trap Name Description OID
mplsLdpInitSessionThresholdExcee
ded
This notification is generated when the back off is
enabled, and the number of Session Initialization
messages exceeds the value of the
'mplsLdpEntityInitSessionThreshold'.
1.3.6.1.2.1.10.
166.4.0.1
mplsLdpPathVectorLimitMismatch This notification is sent when
the'mplsLdpEntityPathVectorLimit' does NOT match the
value of the 'mplsLdpPeerPathVectorLimit' for a specific
Entity.
1.3.6.1.2.1.10.
166.4.0.2
mplsLdpSessionUp If this notification is sent when the value of
'mplsLdpSessionState' enters the 'operational(5)' state.
1.3.6.1.2.1.10.
166.4.0.3
mplsLdpSessionDown This notification is sent when the value of
'mplsLdpSessionState' leaves the 'operational(5)' state.
1.3.6.1.2.1.10.
166.4.0.4
LLDP-MED
Trap Name Description OID
lldpRemTablesChange A lldpRemTablesChange notification is sent when the
value of lldpStatsRemTableLastChangeTime changes.
1.0.8802.1.1.2.
0.0.1
