![D-Link DGS-3630-28SC [713/742] Stacking](/views2/1459303/page713/bg2c9.png)
DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
701
Log Description Severity
Event Description: schedule execute configuration success.
Log Message: Entry <entry-name> to execute configuration <filename> success at time
<time-range>
Parameters Description:
entry-name: The name for this schedule execute configuration entry.
filename: The filename of the configuration.
time-range: The name of the time range.
Informational
Event Description: schedule backup configuration or log success.
Log Message: Entry <entry-name> to backup <type>:<filename> success at time <time-
range>
Parameters Description:
entry-name: The name for this schedule execute configuration entry.
type: Configuration or log.
filename: The filename of the configuration.
time-range: The name of the time range.
Informational
SNMP
Log Description Severity
Event Description: SNMP request received with invalid community string.
Log Message: SNMP request received from <ipaddr> with invalid community string
Parameters Description:
ipaddr: The IP address.
Informational
SRM
Log Description Severity
Event Description: When stacking succeed and the master detects some slave has
different SRM mode.
Log Message: Unit <unitID> SRM mode is different with master
Parameters Description:
unitID: the Unit ID of device in the stacking system.
Alert
SSH
Log Description Severity
Event Description: SSH server is enabled.
Log Message: SSH server is enabled
Informational
Event Description: SSH server is disabled.
Log Message: SSH server is disabled
Informational
Stacking
Log Description Severity
Event Description: Hot insertion. Informational
