DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

DHCP Relay Information Option Format Settings

This window is used to display and configure the DHCP information format.

To view the following window, click Management > DHCP > DHCP Relay > DHCP Relay Information Option

Format Settings, as shown below:

Figure 4-55 DHCP Relay Information Option Format Settings Window

The fields that can be configured in DHCP Relay Information Option Format Global are described below:

Parameter Description

Information Format Remote

Select the DHCP information remote ID sub-option. Options to choose from are

Default, User Define, and Vendor2.

• Default - Select to use the Switch's system MAC address as the remote ID.

• User Define - Select to use a user-defined remote ID. Enter the user-defined

string with the maximum of 32 characters in the text box.

• Vendor2 - Select to use vendor 2 as the remote ID.

• Expert UDF - Select to use the expert UDF remote ID. Select the stand-

alone unit format after this selection here.

Information Format Circuit

Select the DHCP information circuit ID sub-option. Options to choose from are

Default, User Define, and Vendor1.

• Default - Select to use the default circuit ID sub-option.

• User Define - Select to use a user-defined circuit ID. Enter the user-defined

string with the maximum of 32 characters in the text box.

• Vendor1 - Select to use vendor 1 as the circuit ID.

• Expert UDF - Select to use the expert UDF circuit ID. Select the stand-alone

unit format after this selection here.

Click the Apply button to accept the changes made.
