DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
683
Log Description Severity
bias current
TX power
RX power
high-low: High or low threshold.
Event Description: when the any of SFP parameters recovers from the warning threshold.
Log Message: Optical transceiver <interface-id> <component> back to normal
Parameters Description:
interface-id: port interface ID.
component: DDM threshold type. It can be one of the following types:
temperature
supply voltage
bias current
TX power
RX power
Warning
DHCPv6 Client
Log Description Severity
Event Description: DHCPv6 client interface administrator state changed.
Log Message: DHCPv6 client on interface <ipif-name> changed state to [enabled |
disabled]
Parameters Description:
<ipif-name>: Name of the DHCPv6 client interface.
Informational
Event Description: DHCPv6 client obtains an IPv6 address from a DHCPv6 server.
Log Message: DHCPv6 client obtains an ipv6 address <ipv6address> on interface <ipif-
name>
Parameters Description:
ipv6address: IPv6 address obtained from a DHCPv6 server.
ipif-name: Name of the DHCPv6 client interface.
Informational
Event Description: The IPv6 address obtained from a DHCPv6 server starts renewing.
Log Message: The IPv6 address <ipv6address> on interface <ipif-name> starts renewing
Parameters Description:
ipv6address: IPv6 address obtained from a DHCPv6 server.
ipif-name: Name of the DHCPv6 client interface.
Informational
Event Description: The IPv6 address obtained from a DHCPv6 server renews success.
Log Message: The IPv6 address <ipv6address> on interface <ipif-name> renews success
Parameters Description:
ipv6address: IPv6 address obtained from a DHCPv6 server.
ipif-name: Name of the DHCPv6 client interface.
Informational
Event Description: The IPv6 address obtained from a DHCPv6 server starts rebinding.
Log Message: The IPv6 address <ipv6address> on interface <ipif-name> starts rebinding
Parameters Description:
ipv6address: IPv6 address obtained from a DHCPv6 server.
ipif-name: Name of the DHCPv6 client interface.
Informational
Event Description: The IPv6 address obtained from a DHCPv6 server rebinds success.
Log Message: The IPv6 address <ipv6address> on interface <ipif-name> rebinds success
Parameters Description:
ipv6address: IPv6 address obtained from a DHCPv6 server.
Informational
