DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

270

Parameter Description

• Never - Specifies to not to allow the OSPF graceful restart helper mode.

• Only Reload - Specifies to allow the OSPF graceful restart helper mode only

for reload.

• Only Upgrade - Specifies to allow the OSPF graceful restart helper mode

only for upgrade.

Max Grace Period

Enter the maximum grace period value here. The range is from 1 to 1800

seconds.

Click the Apply button to accept the changes made.

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

OSPFv2 Passive Interface Settings

This window is used to display and configure the OSPFv2 passive interface settings.

To view the following window, click L3 Features > OSPF > OSPFv2 > OSPFv2 Passive Interface Settings, as

shown below:

Figure 6-54 OSPFv2 Passive Interface Settings Window

The fields that can be configured are described below:

Parameter Description

Process ID

Enter the OSPF process ID here. The range is from 1 to 65535.

Interface Name

Enter the interface name that will be used here. This name can be up to 12

characters long.

Select the Default option to use the default interface here.

Click the Apply button to accept the changes made.

Click the Delete button to delete the specified entry.

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

OSPFv2 Area Settings

This window is used to display and configure the OSPFv2 area settings.
