DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

To view the following window, click Management > DHCP > DHCP Server > DHCP Server Global Settings, as

shown below:

Figure 4-31 DHCP Server Global Settings Window

The fields that can be configured in DHCP Use Class State are described below:

Parameter Description

DHCP Use Class State

Select to enable or disable the DHCP Use Class State here. When enabled, the

DHCP server will use DHCP classes for address allocation.

Click the Apply button to accept the changes made.

The fields that can be configured in DHCP Server Settings are described below:

Parameter Description

DHCP Ping Packet

Enter the number of ping packets that the Switch will send out on the network

containing the IP address to be allotted. If the ping request is not returned, the IP

address is considered unique to the local network and then allotted to the

requesting client. A value of 0 means there is no ping test. The range is from 0 to

10. The default value is 2.

DHCP Ping Timeout

Enter the amount of time the DHCP server must wait before timing out a ping

packet. The range is from 100 to 10000 milliseconds. The default value is 500

milliseconds.

Click the Apply button to accept the changes made.

DHCP Server Pool Settings

This window is used to display and configure the DHCP server pool settings.

To view the following window, click Management > DHCP > DHCP Server > DHCP Server Pool Settings, as shown

below:

Figure 4-32 DHCP Server Pool Settings Window
