DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
695
Log Description Severity
interface-id: the interface on which the host is authenticated.
Event Description: the authorized user number on an interface is below the maximum user
limit in a time interval.
Log Message: <interface-id> recovers from MAC-based Access Control stop learning
state
Parameters Description:
interface-id: the interface on which the host is authenticated.
Warning
MPLS
Log Description Severity
Event Description: LSP is up.
Log Message: LSP <lsp_id> is up
Parameters Description:
lsp_id: The established LSP ID.
Informational
Event Description: LSP is down.
Log Message: LSP <lsp_id> is down
Parameters Description:
lsp_id: The deleted LSP ID.
Informational
MSTP Debug
Log Description Severity
Event Description: Topology changed.
Log Message: Topology changed [([Instance:<InstanceID>] , <portNum> ,MAC:
<macaddr>)]
Parameters Description:
InstanceID: Instance ID.
portNum: Port ID.
macaddr: MAC address.
Notice
Event Description: Spanning Tree new Root Bridge.
Log Message: [CIST | CIST Regional | MSTI Regional] New Root bridge selected
([Instance: <InstanceID>],MAC: <macaddr>, Priority:<value>)
Parameters Description:
InstanceID: Instance ID.
macaddr: Mac address.
value: priority value.
Informational
Event Description: Spanning Tree Protocol is enabled.
Log Message: Spanning Tree Protocol is enabled
Informational
Event Description: Spanning Tree Protocol is disabled.
Log Message: Spanning Tree Protocol is disabled
Informational
Event Description: New root port.
Log Message: New root port selected [([Instance:<InstanceID>], <portNum>)]
Parameters Description:
InstanceID: Instance ID.
portNum: Port ID.
Notice
Event Description: Spanning Tree port status changed. Notice
