DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

107

Parameter Description

space provided.

Destination

Select the destination Switch Unit ID and type of destination file that will be

copied here. Options to choose from are startup-config, running-config, and

Destination File. Only after selecting the Destination File option can the

destination file path and filename be entered in the space provided. Tick the

Replace check box to replace the current running configuration with the indicated

configuration file.

Click the Apply button to initiate the copy.

Click the Cancel button the discard the process.

Stacking

The Switch supports stacking 9 Switches together while being managed by one console connection to any one of the

console ports on the master Switch, or by an IP address through the MGMT port, or by multiple IP addresses through

any of the RJ45/SFP/SFP+ ports using Telnet, the Web User Interface, and SNMP. This cost effective Switch provides

an affordable solution for administrators to upgrade their networks using the SFP+ ports to scale and stack the

Switches. This increases overall reliability, serviceability, and availability of the network.

• Duplex Chain - The Duplex Chain topology stacks Switches together in a chain-link format. Using this method,

data transfer is only possible in one direction and if there is a break in the chain, then data transfer will be

affected.

• Duplex Ring - The Duplex Ring stacks Switches in a ring or circle format where data can be transferred in two

directions. This topology is very resilient due to the fact that if there is a break in the ring, data can still be

transferred through the stacking cables between Switches in the stack.

Switches in the series can be physically stacked using optical fiber cables connected to SFP+ transceivers or Direct

Attached Cables (DAC) with SFP+ connectors. Only the last 4 ports can be used for physical stacking.

NOTE: When stacking is enabled, the last 2 or 4 SFP+ ports are dedicated stacking ports and cannot

be used for any other purpose. These ports are only able to perform stacking when stacking is

enabled.

Physical stacking needs to be enabled and can be configured to support either a 2-port or a 4-port stacking

configuration. When the 2-port stacking configuration is used, a full-duplex speed of up to 40Gbps will be available

between two Switches. When the 4-port stacking configuration is used, a full-duplex speed of up to 80Gbps will be

available between two Switches.
