DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

398

Click the Back button to return to the previous window.

Click the Delete button to remove the specific entry.

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

After clicking the Summary Prefix List button, the following page will appear.

Figure 6-214 ISIS Router Settings (Summary Prefix List) Window

The fields that can be configured are described below:

Parameter Description

Summary Prefix

Select the level and enter the summary prefix here.

Levels to choose from are:

• Level-1 - Specifies that only routes redistributed into level 1 are summarized

with the configured prefix value.

• Level-1-2 - Specifies that summary routes are applied when redistributing

routes into level 1 and level 2 ISIS and when level 2 ISIS advertises level 1

routes as reachable in its area.

• Level-2 - Specifies that routes learned by level 1 routing are summarized

into the level 2 backbone with the configured IP address and mask value.

Redistributed routes into level-2 ISIS will be summarized also.

Click the Apply button to accept the changes made.

Click the Back button to return to the previous window.

Click the Delete button to remove the specific entry.

Enter a page number and click the Go button to navigate to a specific page when multiple pages exist.

ISIS Interface Settings

This window is used to display and configure the ISIS interface settings.
