DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide
698
Log Description Severity
Parameters Description:
nbr-id: Neighbor's router ID.
Event Description: OSPF router ID was changed.
Log Message: OSPF router ID changed to <router-id>
Parameters Description:
router-id: OSPF router ID.
Informational
Peripheral
Log Description Severity
Event Description: Fan Recovered.
Log Message: Unit <unit-id>, <fan-descr> back to normal
Parameters Description:
Unit <id>: The unit ID.
<fan-descr>: For example, right fan, left fan etc.
Critical
Event Description: Fan Fail.
Log Message: Unit <unit-id> <fan-descr> failed
Parameters Description:
Unit <id>: The unit ID.
<fan-descr>: For example, right fan, left fan etc.
Critical
Event Description: Temperature sensor enters alarm state.
Log Message: Unit <unit-id> <thermal-sensor-descr> detects abnormal temperature
<degree>
Parameters Description:
unitID: The unit ID.
thermal-sensor-descr: Description of the sensor.
degree: The current temperature of the sensor.
Warning
Event Description: Temperature recovers to normal.
Log Message: Unit <unit-id> <thermal-sensor-descr> temperature back to normal
Parameters Description:
unitID: The unit ID.
thermal-sensor-descr: Description of the sensor.
degree: The current temperature of the sensor.
Informational
Event Description: Power failed.
Log Message: Unit <unit-id> <power-descr> failed
Parameters Description:
Unit <id>: The unit ID.
power-descr: Describe the power.
Critical
Event Description: Power is recovered.
Log Message: Unit <unit-id> <power-descr> back to normal
Parameters Description:
Unit <id>: The unit ID.
power-descr: Describe the power.
Critical
Event Description: External Alarm state to change.
Log Message: Uint <unit-id> External Alarm Channel <channelID>:<alarmMsg>
Parameters Description:
Unit <id>: The unit ID.
channelID: The channel ID.
Critical
