DGS-3630 Series Layer 3 Stackable Managed Switch Web UI Reference Guide

274

After clicking the Show Detail button, the following page will appear.

Figure 6-58 OSPFv2 Interface Settings (Show Detail) Window

The fields that can be configured are described below:

Parameter Description

Cost

Enter the cost value here. The range is from 1 to 65535. The interface cost

reflects the overhead for sending the packet across the interface. This cost is

advertised as the link cost in the router link advertisement. The cost is inversely

proportional to the speed of an interface. The cost can be either manually

assigned or be automatically determined. By default, the cost of an interface is

calculated based on reference bandwidth. The cost corresponds to a reference

bandwidth of 1.

Select the Default option to use the default value which is 1.

Hello Interval

Enter the Hello Interval time value here. The range is from 1 to 65535 seconds.

The Hello Interval is advertised in the hello packets. Configure the same hello-

interval for all routers on a specific network. A shorter Hello Interval ensures faster

detection of topological changes but generates more routing traffic and might

cause routing instability.

Select the Default option to use the default value which is 10 seconds.

Dead Interval

Enter the Dead Interval time value here. The range is from 1 to 65535 seconds.

The Dead Interval is the amount of time that the router waits to receive an OSPF

hello packet from the neighbor before declaring the neighbor down. This value is

advertised in the router’s hello packets. It must be the same for all routers on a

specific network. Specifying a smaller Dead Interval ensures faster detection of
