Chapter 10 SIP Account Setup
V300 Series User’s Guide
111
Each field is described in the following table.
Table 27 VoIP > SIP > SIP Settings
LABEL DESCRIPTION
SIP Settings
SIP Account
Select the SIP account you want to see in this screen. At the time of
writing, the V300 supports two SIP accounts.
Active Select this if you want the V300 to use this account. Clear it if you do
not want the V300 to use this account.
Account
Name
Enter your SIP account name, if supplied by your SIP service provider.
Number Enter your SIP number. In the full SIP URI, this is the part before the @
symbol. You can use up to 50 printable English keyboard characters.
SIP Local
Port
Enter the V300’s listening port number, if your VoIP service provider
gave you one. Otherwise, keep the default value.
SIP Server
Address
Enter the IP address or domain name of the SIP server provided by
your VoIP service provider. You can use up to 32 printable English
keyboard characters. It does not matter whether the SIP server is a
proxy, redirect or register server.
SIP Server
Port
Enter the SIP server’s listening port number, if your VoIP service
provider gave you one. Otherwise, keep the default value.
REGISTER
Server
Address
Enter the IP address or domain name of the SIP register server, if your
VoIP service provider gave you one. Otherwise, enter the same address
you entered in the SIP Server Address field. You can use up to 32
printable English keyboard characters.
REGISTER
Server Port
Enter the SIP register server’s listening port number, if your VoIP
service provider gave you one. Otherwise, enter the same port number
you entered in the SIP Server Port field.
SIP Server
Domains
Enter the SIP server domain name. In the full SIP URI, this is the part
after the @ symbol. You can use up to 32 printable English keyboard
characters.
Send Caller
ID
Select this if you want to send identification when you make VoIP phone
calls. Clear this if you do not want to send identification.
Voice Mail
Number
Enter the voicemail number associated with this SIP account.
DNS SRV Select this to use the DNS server(s) you configured in the Network >
Ethernet > Internet Connection screen.
Backup SIP Server
1st / 2nd
Backup SIP
Server
Select the check box to have the V300 use the backup SIP server(s)
you configure. If the V300 cannot use the server you configured in the
SIP Settings section of this screen, it tries to use the backup
server(s). It tries to use the 1st Backup SIP Server and, if it cannot
connect, then tries to use the 2nd Backup SIP Server.
SIP Service
Address
Enter the IP address or domain name of the backup SIP server provided
by your VoIP service provider. You can use up to 32 printable English
keyboard characters. It does not matter whether the SIP server is a
proxy, redirect or register server.
SIP Service
Port
Enter the backup SIP server’s listening port number, if your VoIP service
provider gave you one. Otherwise, keep the default value.
