Zyxel V301-T1 [71/240] The static ip menu
![Zyxel V301-T1 [71/240] The static ip menu](/views2/1013116/page71/bg47.png)
Chapter 6 LCD Menus: Advanced
V300 Series User’s Guide
71
6.5 DHCP
Use DHCP to have the V300 get an IP address automatically from a DHCP server
on the network.
Select Adv Setting > DHCP. The following screen displays.
Figure 54 LCD Menu: DHCP
Check whether DHCP is enabled on the V300 or not.
If DHCP is disabled (Off), press to enter the DHCP screen and press again to
change the configuration (turn DHCP on). Alternatively press to return to the
previous screen.
Note: If static IP or PPPoE is enabled, DHCP will be disabled automatically.
6.6 The Static IP Menu
Use this menu to manually configure your V300’s IP address, subnet mask and
gateway settings. Enter the settings exactly as your ISP or network administrator
gave them to you.
Select Adv Setting > Static IP. The following screen displays.
Figure 55 LCD Menu: Static IP
Press to toggle static IP OFF and ON.
The following table describes the other labels in this section.
1. DHCP
On
1. Static IP
Off
Table 13 LCD Menu: Static IP
LABEL DESCRIPTION
Static IP Select this to turn on static IP. Your V300 uses the IP settings you
configure in this menu. If DHCP or PPPoE is enabled, static IP will
be disabled automatically.
IP Address Select this to set the static IP address you want the V300 to use.
Gateway Select this to set the IP address of the device your V300 uses to
access the Internet.
