Chapter 10 SIP Account Setup
V300 Series User’s Guide
118
Enable VLAN
Tag
Select this if the V300 has to be a member of a VLAN to communicate
with the SIP server. Ask your network administrator if you are unsure.
Otherwise, clear this field.
Voice VLAN
Priority
If the V300 is a member of a VLAN group, you may choose a priority
level for its VoIP traffic within the VLAN. The priority level is from 0-7,
with 0 being the lowest level and 7 being the highest level. You can
assign the V300 with a higher traffic priority for better voice quality.
Voice VLAN
ID
Enter the VLAN ID provided by your network administrator. Your LAN
and gateway must be configured to use VLAN tags.
Apply
Click this to save your changes.
Reset Click this to set every field in this screen to its last-saved value.
Table 29 VoIP > SIP > QoS
LABEL DESCRIPTION
