Chapter 14 Logs
V300 Series User’s Guide
146
14.3 SIP Message
Click Maintenance > Logs > SIP Message to open this screen.
You can view SIP server messages and responses in this screen. Once the log is
full, old messages are deleted as new ones are created.
Figure 106 Maintenance > SIP Message
The following table describes the labels in this screen.
# This is the log’s index number.
Time This field displays the time the log was recorded.
Message This field states the reason for the log.
Source This field lists the source IP address and the port number of the
incoming packet that caused the log, if applicable.
Destination This field lists the destination IP address and the port number of the
outgoing packet that caused the log, if applicable.
Note This field displays additional information about the log entry.
Table 43 Maintenance > Logs (continued)
LABEL DESCRIPTION
Table 44 Maintenance > SIP Message
LABEL DESCRIPTION
Refresh Click this to refresh the V300 SIP messages.
Clear Message Click this to clear all existing SIP messages in the V300.
