Chapter 6 LCD Menus: Advanced
V300 Series User’s Guide
67
6.3.9 SIP Password
Use this screen to see and edit the password for your SIP account. Select Adv
Setting > VoIP1 or VoIP2 > Password. The following screen displays.
Figure 43 LCD Menu: Authentication Password
If a SIP authentication password is already configured on the V300, it displays in
this screen as a row of asterisks (*). If no SIP authentication password is already
configured, no asterisks display. Each asterisk represents one character of the
password configured on the V300. Press to edit the SIP authentication
password, or press to return to the previous screen.
6.3.9.1 Authentication Password - Edit
Press in the Password screen. The following screen displays.
Figure 44 LCD Menu: Authentication Password - Edit
Use PHONEBOOK to clear the previously-saved settings if any. Enter the new SIP
authentication password. Press to save the change. Alternatively, press to
return to the previous screen.
6.4 The Auto Provision Menu
The auto provision menu lets you set up the V300 to receive its configuration data
automatically from the SIP server to which it is registered.
Select Adv Setting > Auto Prov and press , upon which you are prompted to
enter the V300’s admin password (the default is ‘1234’)
. If you make a mistake,
press the PHONEBOOK key to delete your entry one number at a time.
Figure 45 LCD Menu: Admin Password Entry
9. Password
9. Password 1
_
Password:
