Chapter 3 Using the LCD Screen
V300 Series User’s Guide
46
3.3 Enabling and Disabling Features
Many of the V300’s LCD screen menus allow you check a feature’s settings and
then edit the setting. Take the following steps to check a feature’s current setting
and then enable or disable the feature. This example uses the DHCP feature.
1 Select the feature you want to configure. In this example, press MENU to enter
the menu system, then select Adv Setting. In the Adv Setting menu, select
DHCP.
The following screen displays:
Figure 8 Example: DHCP
2 To change the setting to ON, press .
Note: If later you decide you want to use static IP or PPPoE, then you do not need to
come into the DHCP menu to disable it; rather, just go into one of those other
menus and enable one of them. This automatically turns DHCP off.
3.4 Entering Numbers, Letters and Symbols
When you enter information into the V300 (when setting up a phonebook entry,
for example) you may need to enter different kinds of characters. The
alphanumeric keypad has four input modes:
•Number mode
•Uppercase mode
•Lowercase mode
•Symbol mode
Use the # key to cycle between modes.
Note: Not all modes are available in all screens.
When you press a key to enter a character, wait a short time until the cursor
moves on to the next space. Press a key multiple times to access the different
characters. For example, in Uppercase mode press 9 four times to enter “
Z”.
