Zyxel V301-T1 [145/240] Overview

V300 Series User’s Guide

145

CHAPTER 14

Logs

14.1 Overview

This chapter contains information on viewing your V300’s logs.

14.2 Logs Screen

Click Maintenance > Logs to open the Logs screen.

You can view logs and alert messages in this screen. Once the log table is full, old

logs are deleted as new logs are created.

Click a column heading to sort the entries. A triangle indicates the direction of the

sort order.

Figure 105 Maintenance > Logs

The following table describes the labels in this screen.

Table 43 Maintenance > Logs

LABEL DESCRIPTION

Logs

Display Select a category of logs to view.

Refresh Click Refresh to renew the log screen.

Clear Log Click Clear Log to delete all the logs.
