![Zyxel V301-T1 [63/240] Sip server address](/views2/1013116/page63/bg3f.png)
Chapter 6 LCD Menus: Advanced
V300 Series User’s Guide
63
6.3.3 SIP Server Address
Use this menu to see and edit the IP address of the SIP server for your account.
Select Adv Setting > VoIP1 or VoIP2 > Serv Addr. The following screen
displays.
Figure 31 LCD Menu: SIP Server Address
The IP address of the SIP server already configured on the V300 displays. If no IP
address is already configured, none displays. Press to edit the SIP server
address, or press to return to the previous screen.
6.3.3.1 SIP Server Address - Edit
Press in the Serv Addr screen. The following screen displays.
Figure 32 LCD Menu: SIP Server Address - Edit
Use PHONEBOOK to clear the previously-saved settings if any. Enter the new SIP
server address and press to save the change. Alternatively, press to return to
the previous screen.
6.3.4 SIP Server Port
Use this screen to see and edit the port on the this account’s SIP server used for
SIP calls. Select Adv Setting > VoIP1 or VoIP2 > Serv Port. The following
screen displays.
Figure 33 LCD Menu: SIP Server Port
This screen displays the SIP server port number on the V300. The default is 5060.
Press to edit the SIP server port number, or press to return to the previous
screen.
Note: Make no changes in this screen unless your service provider told you to.
3. Serv Addr
3. Serv Addr 1
_
4. Serv Port
5060
