Chapter 6 LCD Menus: Advanced
V300 Series User’s Guide
62
Select Adv Setting > VoIP1 or VoIP2 > SIP Active and enter the password
when prompted. The following screen displays.
Figure 28 LCD Menu: SIP Active
Press to toggle between the ON and OFF settings.
6.3.2 SIP Number
Use this to see and edit the SIP number for your SIP account.
Note: If you have a SIP account like “1234567@voip-provider.com”, the SIP Number
is “1234567”.
Select Adv Setting > VoIP1 or VoIP2 > SIP1 Num. The following screen
displays.
Figure 29 LCD Menu: SIP Number
If a SIP account number is already configured, it displays. Otherwise, no SIP
number displays. Press to edit the SIP number, or press to return to the
previous screen.
6.3.2.1 SIP Number - Edit
Press in the SIP Num screen. The following screen displays.
Figure 30 LCD Menu: SIP Number - Edit
Use PHONEBOOK to clear the previously-saved settings if any. Enter the new SIP
account number and press to save the change. Alternatively, press to return
to the previous screen.
1. SIP1/2 Active
On
2. SIP1 Num
2 SIP1 Num 1
_
