Chapter 16 Troubleshooting
V300 Series User’s Guide
162
The V300’s DNS (Domain Name Service) settings may be misconfigured. See the
suggestions about DNS in the troubleshooting section for “I cannot make VoIP
calls.”.
If this does not help, the phone of the person you are calling may be
malfunctioning or misconfigured.
I can make phonecalls, but I cannot receive them.
or
I can receive some phonecalls, but not others.
Check your V300’s call forwarding settings in the VoIP > Phone Book > Call Forward
screen (see Section 12.2 on page 127). If they are misconfigured, certain calls
may be mistakenly forwarded.
All my VoIP calls are of poor audio quality.
• If your ISP or network administrator gave you SIP TOS or RTP TOS values to
use, enter them in the web configurator’s VoIP > SIP > QoS screen (see
Section 10.3 on page 117).
• If your V300 is connected to a router with configurable bandwidth management
settings, check these settings. Consult the router’s documentation for more
information.
• Make sure that your V300 uses the voice codecs recommended by your VoIP
service provider (see Section 6.5 on page 71).
I cannot use some calling features.
Many of the features your V300 supports depend on your VoIP service provider.
You may have to subscribe to certain services. Contact your VoIP service provider
for more information.
The incoming or outgoing audio is too quiet or too loud.
or
I cannot hear the V300’s ring when a call is incoming.
Use the VOLUME keys to increase or decrease the volume.
