Chapter 16 Troubleshooting
V300 Series User’s Guide
159
3 Make sure your Internet browser does not block pop-up windows and has
JavaScripts and Java enabled. See Appendix C on page 201.
4 Make sure your computer is in the same subnet as the V300. (If you know that
there are routers between your computer and the V300, skip this step.)
• If there is no DHCP server on your network, make sure your computer’s IP
address is in the same subnet as the V300. See Appendix B on page 171.
5 If the problem continues, contact the network administrator or vendor, or try one
of the advanced suggestions.
Advanced Suggestions
• Try to access the V300 using another service, such as Telnet.
I can see the Login screen, but I cannot log in to the V300.
1 Make sure you have entered the user name and password correctly. The default
password is 1234. This field is case-sensitive, so make sure [Caps Lock] is not on.
2 You cannot log in to the web configurator while someone is using Telnet to access
the V300. Log out of the V300 in the other session, or ask the person who is
logged in to log out.
3 Disconnect and re-connect the power adaptor or cord to the V300.
4 If this does not work, you have to reset the device to its factory defaults. See
Section 2.2.2 on page 37.
I cannot Telnet to the V300.
See the troubleshooting suggestions for I cannot see or access the Login screen in
the web configurator. Ignore the suggestions about your browser.
I cannot use FTP to upload / download the configuration file. / I cannot use FTP to
upload new firmware.
See the troubleshooting suggestions for I cannot see or access the Login screen in
the web configurator. Ignore the suggestions about your browser.
