Chapter 6 LCD Menus: Advanced
V300 Series User’s Guide
64
6.3.4.1 SIP Server Port - Edit
Press in the Serv Port screen. The following screen displays.
Figure 34 LCD Menu: SIP Server Port - Edit
Use PHONEBOOK to clear the previously-saved settings if any. Enter the new SIP
server port number (from 1024 to 65535) and press to save the change.
Alternatively, press to return to the previous screen.
Note: The port number can consist of numerals (0 ~ 9) only.
6.3.5 SIP Register Server
Use this menu to see and edit the IP address of the server your SIP service
provider uses to register the V300. Select Adv Setting > VoIP1 or VoIP2 > Reg
Addr. The following screen displays.
Figure 35 LCD Menu: SIP Register Server
The IP address of the SIP register server already configured on the V300 displays.
If no IP address is already configured, none displays. Press to edit the SIP
register server address, or press to return to the previous screen.
6.3.5.1 SIP Register Server - Edit
Press in the Reg Addr screen. The following screen displays.
Figure 36 LCD Menu: SIP Register Server Address - Edit
Use PHONEBOOK to clear the previously-saved settings if any. Enter the new SIP
register server address and press to save the change. Alternatively, press to
return to the previous screen.
4. Serv Port 1
5060_
5. Reg Addr
5. Reg Addr 1
_
