Chapter 16 Troubleshooting
V300 Series User’s Guide
158
3 Inspect your cables for damage. Contact the vendor to replace any damaged
cables.
4 Disconnect and re-connect the power adaptor to the V300.
5 If the problem continues, contact the vendor.
I forgot the IP address for the V300.
1 The V300 is set to get an IP address automatically by default. Check the IP
address in the System Info > IP Address > IP Address LCD menu.
2 Set a static IP address for the V300 in the Adv Setting > Network > Static IP
menus (see Section 6.6 on page 71).
3 Alternatively, use the management IP address to log in to the V300 (see Section
9.3 on page 100).
I forgot the password.
1 The default password is 1234.
2 If this does not work, you have to reset the device to its factory defaults. See
Section 2.2.2 on page 37.
I cannot see or access the Login screen in the web configurator.
1 Make sure you are using the correct IP address.
• The V300 is set to get an IP address automatically by default. Check the IP
address it is using in the System Info > IP Address > IP Address LCD
menu.
• If you changed the IP address (Section on page 97), use the new IP address.
• If you changed the IP address and have forgotten it, see the troubleshooting
suggestions for I forgot the IP address for the V300.
2 Check the hardware connections, and make sure the LEDs and the LCD screen are
behaving as expected. See the Quick Start Guide and Section 2.2 on page 32.
