Chapter 5 LCD Menus: Basic Settings
V300 Series User’s Guide
54
5.3 The Phonebook Menu
Use the phonebook to view a list of your contacts.
Select MENU > Phonebook. The following screen displays. This is the same
function as pressing the actual PHONEBOOK button.
Figure 16 LCD Menu: Phonebook
If you want to add, edit or remove an entry in the phonebook, use the web
configurator. See Chapter 7 on page 83 for more information.
If you want to add a call record in the phonebook or call a phonebook contact, see
Chapter 4 on page 51.
5.4 The Volume Setting Menu
Use these menus to set the loudness of the V300’s audio equipment.
Select MENU > Vol Setting. The following screen displays.
Figure 17 LCD Menu: Volume Setting
The following table describes the labels in this screen.
1. Ann
1234
2. Vol Control
1. Speaker Volume
Table 8 LCD Menu: Volume Setting
LABEL DESCRIPTION
Speaker Volume Select this to set the internal speakerphone volume. This controls
both the internal speaker and the internal microphone.
Phone Volume Select this to set the handset volume. This controls both the
handset’s speaker and its microphone.
Ring Volume Select this to set the volume of the V300’s ringtone. This setting
applies to all configured group rings.
Headset Volume Select this to set the volume of an attached headset (or any
device connected to the external speaker and/or microphone
sockets). This controls both the handset’s speaker (earpiece) and
its microphone.
