Chapter 7 The Web Configurator
V300 Series User’s Guide
87
7.2.3 Main Window
The main window displays information and configuration fields. It is discussed in
the rest of this document.
Right after you log in, the Status screen is displayed. See Chapter 8 on page 89
for more information about the Status screen.
7.2.4 Status Bar
Check the status bar when you click Apply or OK to verify that the configuration
has been updated.
Phone Book Call Forward Use this screen to redirect incoming calls to other phone
numbers.
Contact List Use this screen to view, edit and add to your list of phonebook
entries.
Group List Use this screen to view and edit the groups to which your
phonebook entries belong.
Block List Use this screen to view and edit the phone numbers that you
prevent from calling you.
DND White List Use this screen to view and edit the list of people who can call you
even when DND (Do Not Disturb) is turned on.
Maintenance
System General This screen contains administrative and system-related
information and also allows you to change your password.
Time Setting Use this screen to change your V300’s time and date.
Dynamic DNS Use this screen to map your current dynamic IP address with one
or many dynamic DNS services so that anyone can contact you.
Clock Alarm
Setting
Use this screen to set your V300’s three built-in clock alarms.
Logs View Log Use this screen to display your device’s logs.
SIP Message Use this screen to view SIP server messages and responses.
Tools Firmware Use this screen to upload firmware to your device.
Configuration Use this screen to backup and restore your device’s configuration
(settings) or reset the factory default settings.
Restart This screen allows you to reboot the V300 without turning the
power off.
Ring
Maintenance
Use this screen to upload files to the V300 and use them as
ringtones.
Packet Mirror Use this screen to send data packets from the V300 to another IP
address, where they can be analyzed to clarify Internet-related
issues.
Table 19 Navigation Panel Summary
LINK TAB FUNCTION
