Chapter 6 LCD Menus: Advanced
V300 Series User’s Guide
65
6.3.6 SIP Register Port
Use this screen to see and edit the listening port on the SIP register server for
calls from this account. Select Adv Setting > VoIP1 or VoIP2 > Reg Port. The
following screen displays.
Figure 37 LCD Menu: SIP Register Port
This screen displays the SIP register server port number on the V300. The default
is 5060. Press to edit the SIP register server port number, or press to return
to the previous screen.
Note: Make no changes in this screen unless your service provider told you to.
6.3.6.1 SIP Register Port - Edit
Press in the Reg Port screen. The following screen displays.
Figure 38 LCD Menu: SIP Register Port - Edit
Use PHONEBOOK to clear the previously-saved settings if any. Enter the new SIP
server port number (from 1024 to 65535) and press to save the change.
Alternatively, press to return to the previous screen.
Note: The port number can consist of numerals (0 ~ 9) only.
6.3.7 SIP Service Domain
Use this to see and edit the SIP service domain configured for your SIP account.
The SIP service domain of the VoIP service provider (the company that lets you
make phonecalls over the Internet) is the domain name in a SIP URI. For example,
if the SIP address is “1122334455@voip-provider.com”, then “voip-provider.com”
is the SIP service domain.
Select Adv Setting > VoIP1 or VoIP2 > Domain. The following screen displays.
Figure 39 LCD Menu: SIP Service Domain
6. Reg Port
5060
6. Reg Port 1
5060_
7. Domain
