Chapter 10 SIP Account Setup
V300 Series User’s Guide
114
Each field is described in the following table.
Table 28 VoIP > SIP > SIP Settings > Advanced Setup
LABEL DESCRIPTION
SIP Server Settings
URL Type Select whether or not to include the SIP service domain name when the
V300 sends the SIP number.
SIP - include the SIP service domain name
TEL - do not include the SIP service domain name
Expiration
Duration
Enter the number of seconds your SIP account is registered with the
SIP register server before it is deleted. The V300 automatically tries to
re-register your SIP account when one-half of this time has passed.
(The SIP register server might have a different expiration.)
Register Re-
send timer
Enter the number of seconds the V300 waits before it tries again to
register the SIP account, if the first try failed or if there is no response.
Session
Expires
Active
Select this to have the V300 use the setting you configure in the
Session Expire field. If you do not select this, the V300 does not
automatically disconnect calls.
Session
Expires
Enter the number of seconds the conversation can last before the call is
automatically disconnected. Usually, when one-half of this time has
passed, the V300 or the other party updates this timer to prevent this
from happening.
Min-SE Enter the minimum number of seconds the V300 accepts for a session
expiration time when it receives a request to start a SIP session. If the
request has a shorter time, the V300 rejects it.
RTP Port Range
Start Port
End Port
Enter the listening port number(s) for RTP traffic, if your VoIP service
provider gave you this information. Otherwise, keep the default values.
To enter one port number, enter the port number in the Start Port and
End Port fields.
To enter a range of ports,
• enter the port number at the beginning of the range in the Start
Port field
• enter the port number at the end of the range in the End Port field.
Voice
Compression
