Chapter 13 System
V300 Series User’s Guide
138
13.3 General Screen
Use this screen to change system settings and the web configurator password, or
to set the administrator inactivity timer.
Note: If you forget your password you will need to reset the device. See your Quick
Start Guide for details.
Click Maintenance > System > General. The following screen displays.
Figure 101 Maintenance > System > General
The following table describes the labels in this screen.
Table 39 Maintenance > System > General
LABEL DESCRIPTION
System Setup
System
Name
System Name is a unique name to identify the V300 in an Ethernet
network. It is recommended you enter your computer’s “Computer
name” in this field.
This name can be up to 30 alphanumeric characters long. Spaces are
not allowed, but dashes “-” and underscores "_" are accepted.
Domain
Name
Enter the domain name (if you know it) here. If you leave this field
blank, the ISP may assign a domain name via DHCP.
The domain name entered by you is given priority over the ISP assigned
domain name.
