Chapter 13 System
V300 Series User’s Guide
139
Administrato
r Inactivity
Timer
Type how many seconds a management session can be left idle before
the session times out. After it times out you have to log in with your
password again. Very long idle timeouts may have security risks. The
default is 0 seconds, which means a management session never times
out, no matter how long it has been left idle.
Password Setup Set up both the Admin and User level passwords in this section.
Both accounts can log into the web configurator and change its settings,
but the User account has some limitations on what it is allowed to do.
The User account:
• Cannot access the SIP screens or configure them.
• Cannot access the Tools screens or configure them.
Old
Password
Type in your existing system password (“1234” is the default
password).
New
Password
Type your new system password.
Note: The new password must be between 4 and 8 numerals (0 ~
9) long. Letters, spaces and other characters are not allowed.
Note that as you type a password, the screen displays an asterisk (*)
for each character you type.
Retype to
Confirm
Retype your new system password for confirmation.
Apply Click this to save your changes back to the device.
Reset Click this to reload the previous configuration for this screen.
Table 39 Maintenance > System > General (continued)
LABEL DESCRIPTION
