Chapter 12 The Phone Book
V300 Series User’s Guide
131
12.4 Group List Screen
Use this screen to see and edit the calling groups to which your phonebook
contacts belong.
Note: You can also edit this information in the VoIP > Phone Book > Contact List
screen.
DND White Select this if you want this contact to be able to call you even when
DND (Do Not Disturb) is turned on.
Modify Click the Add button to include the new entry in the phonebook, or to
save the changes you made to an existing entry.
Phone Book
Table
Page Select a page from the list to go to that page of contacts.
Sort By
Select a method for sorting the items in your phonebook.
Item This shows the index number of the contact’s entry.
Number This is the contact’s phone number.
Name This is the contact’s name.
Group This is the calling group to which the contact belongs.
Assign
Account
This is the SIP account the V300 always uses to call this contact. This
shows None if you can use any SIP account to call the contact.
Block This is selected if this contact is prevented from calling you.
DND White
This is selected if this contact can call you even when DND (Do Not
Disturb) is turned on.
Modify Click the Edit icon to change this entry’s details.
Click the Delete icon to remove the entry from the phonebook. If you
do this, the information cannot be recovered.
Apply
Click this to save your settings.
Clear All Click this to remove all the entries from the phonebook. If you do this,
the information cannot be recovered.
Backup Click this to save your phonebook as an *.ini file.
Restore
Click this restore a previously saved phonebook file.
When you click the Restore button, a filename field, Browse button
and Upload button appear. Use the Browse button to locate the
previously saved phonebook book then click the Upload button to load
it into the web configurator, which then updates your phone.
Table 35 VoIP > Phone Book > Contact List (continued)
LABEL DESCRIPTION
