![Zyxel V301-T1 [165/240] Product specifications](/views2/1013116/page165/bga5.png)
V300 Series User’s Guide
165
APPENDIX A
Product Specifications
The following tables summarize the V300’s hardware and firmware features.
Table 49 Hardware Specifications
Dimensions (W x D x H) 16.5mm x 208mm x 91.5mm
Weight 465g
Power Specification 12V DC, 1.5A
Power over Ethernet
(PoE) - V301 Only
IEEE 802.3af compliant.
Ethernet Ports Auto-negotiating: 10 Mbps or 100 Mbps in either half-duplex
or full-duplex mode.
Use crossover Ethernet cables.
Handset Port RJ-11 telephone connector.
(Headset) Microphone
Port
3.5mm
(Headset) Headphone
Port
3.5mm
Operation Temperature 0 ~ 40 C
Storage Temperature -30 ~ 60 C
Operation Humidity 20 ~ 95% RH
Storage Humidity 20 ~ 95% RH
Distance between the
centers of the holes (for
wall mounting) on the
device’s back.
100mm
Recommended type of
screws for wall-mounting
M4 Tap Screw, see Figure 120 on page 169.
