![Zyxel V301-T1 [157/240] Troubleshooting](/views2/1013116/page157/bg9d.png)
V300 Series User’s Guide
157
CHAPTER 16
Troubleshooting
16.1 Overview
This chapter offers some suggestions to solve problems you might encounter. The
potential problems are divided into the following categories.
• Power, Hardware Connections, and LEDs
• Internet Access
• Phone Calls and VoIP
16.2 Power, Hardware Connections, and LEDs
The V300 does not turn on. None of the LEDs turn on.
1 Make sure you are using the power adaptor or cord included with the V300.
2 Make sure the power adaptor or cord is connected to the V300 and plugged in to
an appropriate power source. Make sure the power source is turned on.
3 Disconnect and re-connect the power adaptor or cord to the V300.
4 If the problem continues, contact the vendor.
One of the keys or LEDs does not behave as expected.
1 Make sure you understand the normal behavior of the key or LED. See Section 2.2
on page 32.
2 Check the hardware connections. See the Quick Start Guide and Section 2.2 on
page 32.
