Chapter 8 The Status Screens
V300 Series User’s Guide
95
Codec This field displays what voice codec (coder/decoder) is being used for a
current VoIP call.
Duration This field displays how long the current call has lasted.
Packets Sent This field displays the number of packets the V300 has transmitted in
the current call.
Packets Recv This field displays the number of packets the V300 has received in the
current call.
Tx Rate This field displays how quickly the V300 has transmitted packets in the
current call. The rate is the average number of bytes transmitted per
second.
Rx Rate This field displays how quickly the V300 has received packets in the
current call. The rate is the average number of bytes transmitted per
second.
Poll Interval(s) Enter how often you want the V300 to update this screen, and click Set
Interval.
Set Interval Click this to make the V300 update the screen based on the amount of
time you specified in the Poll Interval field.
Stop Click this to make the V300 stop updating the screen.
Table 22 VoIP Statistics
LABEL DESCRIPTION
