Chapter 15 Tools
V300 Series User’s Guide
152
If the upload was not successful, the following screen will appear. Click Return to
go back to the Configuration screen.
Figure 114 Configuration Restore Error
15.3.3 Save Debug Log
Save Debug Log allows you save a copy of the V300’s debug log to your computer.
This is useful if you encounter any problems with the device and need to talk to
customer support.
15.3.4 Back to Factory Defaults
Back to Factory Defaults let you clear all user-entered configuration information
and returns the V300 to its factory defaults.
You can also press the RESET button on the rear panel to reset the factory
defaults of your V300. Refer to the chapter about introducing the web configurator
for more information on the RESET button.
15.4 Restart Screen
System restart allows you to reboot the V300 without turning the power off.
Click Maintenance > Tools > Restart. Click Restart to have the V300 reboot.
This does not affect the V300's configuration.
Figure 115 Maintenance > Tools > Restart
