Chapter 2 Hardware
V300 Series User’s Guide
36
The following table describes the rear panel hardware.
Figure 7 Base Panel Hardware
The following table describes the rear panel hardware.
Table 4 Rear Panel Hardware
LABEL DESCRIPTION
1 Power socket Attach the included power adaptor, if you are not using
Power over Ethernet (V301 only). See the product
specifications appendix for power supply specifications.
Note: Use only the power adaptor and cable that
came with your V300.
2 LAN port Use an Ethernet cable to connect to your network.
3 PC port Use an Ethernet cable to connect a computer for
configuration, or to access the Internet.
Table 5 Base Panel Hardware
LABEL DESCRIPTION
1 Wall-mounting holes Use these to hang the V300 on a wall. See the wall-
mounting appendix for details.
2 Handset port Use this to attach the included handset cable’s RJ-11
connector.
