![Zyxel V301-T1 [66/240] Sip user id](/views2/1013116/page66/bg42.png)
Chapter 6 LCD Menus: Advanced
V300 Series User’s Guide
66
If a SIP domain is already configured on the V300, it displays in this screen. If no
SIP domain is already configured, none displays. Press to edit the SIP domain,
or press to return to the previous screen.
6.3.7.1 SIP Service Domain - Edit
Press in the Domain screen. The following screen displays.
Figure 40 LCD Menu: SIP Service Domain - Edit
Use PHONEBOOK to clear the previously-saved settings if any. Enter the new SIP
service domain. If you have a SIP account like “1234567@voip-provider.com”, the
SIP service domain is “voip-provider.com”. Press to save the change.
Alternatively, press to return to the previous screen.
6.3.8 SIP User ID
A SIP account’s user ID is its username. Select Adv Setting > VoIP1 or VoIP2 >
User ID to see and edit the SIP user name for your SIP account. The following
screen displays.
Figure 41 LCD Menu: SIP User ID
If a SIP authentication ID is already configured on the V300, it displays in this
screen. If no SIP authentication ID is already configured, none displays. Press
to edit the SIP authentication ID, or press to return to the previous screen.
6.3.8.1 SIP Authentication ID - Edit
Press in the User ID screen. The following screen displays.
Figure 42 LCD Menu: SIP User ID - Edit
Use PHONEBOOK to clear the previously-saved settings if any. Enter the new SIP
authentication ID. Press to save the change. Alternatively, press to return to
the previous screen.
7. Domain 1
_
8. User ID
8. User ID 1
_
