Chapter 3 Using the LCD Screen
V300 Series User’s Guide
49
3.6 The LCD Status Screen
When you first turn on the V300 or make a call, the status screen displays. The
status screen is divided into two main sections, as shown below.
Figure 9 LCD Status Screen
In the status screen, the upper line displays the time and date configured on the
V300, and the lower line displays information about the SIP account. The SIP
account’s name displays if it is successfully registered. If it has tried to register
but failed, NoReg displays. If the SIP account is not enabled (see Section 6.3.1 on
page 61) NoUse displays.
When the phone is in Flexworker mode (see Section 6.11 on page 78 for more), a
small ‘F’ icon on the right side.
Figure 10 Flexworker Icon
09:45 2010-01-01
SIP1 1234
