Chapter 6 LCD Menus: Advanced
V300 Series User’s Guide
68
Press once again after entering the password. If correct, the following screen
displays.
Figure 46 LCD Menu: DHCP
See the following sections for more information on each menu in this screen.
6.4.1 Auto Provision Active
When the auto provision feature is set to ON, the V300 then receives all the
information it needs to be immediately usable from the SIP server to which it is
registered. This is a zero-configuration option that automatically determines the
phone’s extension number, IP address, and other relevant network data. However,
before this feature can be fully utilized the SIP server must be configured in
advance to provide the settings needed by the V300.
Select Adv Setting > Auto Prov > Active and enter the password when
prompted. The following screen displays.
Figure 47 LCD Menu: DHCP
Press to toggle auto provisioning OFF and ON.
6.4.2 Protocol
Select Adv Setting > Auto Prov > Protocol. The following screen displays.
Figure 48 LCD Menu: Protocol
1. Active
Table 11 LCD Menu: SIP Account Configuration
Active see Section 6.4.1 on page 68
Protocol see Section 6.4.2 on page 68
Serv Addr see Section 6.4.3 on page 69
Serv Port see Section 6.4.4 on page 70
Expire Time see Section 6.4.5 on page 70
Retry Time see Section 6.4.6 on page 70
1. Active
2. Protocol
