Appendix A Product Specifications
V300 Series User’s Guide
166
Speakerphone Internal speaker and microphone.
Phone Functions Call forwarding
Call transferring
Conference calling
Last number redial
Voicemail
Call muting
Do Not Disturb
Phonebook
Table 50 Firmware Specifications
FEATURE DESCRIPTION
Default DHCP status Client
Default management IP
address
192.168.5.1
Default Password 1234
Device Management Use the V300’s LCD screen menus or the web configurator to
easily configure the rich range of features.
Firmware Upgrade Download new firmware (when available) from the ZyXEL web
site and use the web configurator, an FTP or a TFTP tool to put
it on the V300.
Note: Only upload firmware for your specific model!
Configuration Backup &
Restoration
Make a copy of the V300’s configuration. You can put it back on
the V300 later if you decide to revert back to an earlier
configuration.
Network Address
Translation (NAT)
Each computer on your network must have its own unique IP
address. Use NAT to convert your public IP address(es) to
multiple private IP addresses for the computers on your
network.
Time and Date Get the current time and date from an external server when
you turn on your V300. You can also set the time manually.
These dates and times are then used in logs.
Logging and Tracing Use packet tracing and logs for troubleshooting. You can send
logs from the V300 to an external syslog server.
PPPoE PPPoE mimics a dial-up Internet access connection.
Remote Management This allows you to decide whether a service (HTTP or FTP traffic
for example) from a computer on a network (LAN or WAN for
example) can access the V300.
Embedded FTP and TFTP
Servers
The embedded FTP and TFTP servers enable fast firmware
upgrades as well as configuration file backups and restoration.
Table 49 Hardware Specifications
