Chapter 6 LCD Menus: Advanced
V300 Series User’s Guide
61
Note: Once you have configured the fields in these menus with the correct
information, the V300 must register with the SIP server. You may need to restart
the V300 to do this.
Note: Enter information in these menus exactly as you received it from your VoIP
service provider. If you were not given information for any menu or field, leave it
at its default setting.
Select Adv Setting > VoIP1 or VoIP2 and press , upon which you are
prompted to enter the V300’s admin password (the default is ‘1234’)
. If you make
a mistake, press the PHONEBOOK to delete your entry one number at a time.
Figure 26 LCD Menu: Admin Password Entry
Press once again after entering the password. If correct, the following screen
displays.
Figure 27 LCD Menu: SIP Active
See the following sections for more information on each menu in this screen.
6.3.1 SIP Active
Use this screen to set whether the SIP account linked is active or not.When the
account is inactive, you cannot make or receive calls on the V300 using that
account. You can, however, use the other account, assuming it is active. If both
are inactive, then the V300 cannot make or receive any phone calls whatsoever.
1. SIP1/2 Active
On
Table 10 LCD Menu: SIP Account Configuration
SIP Active see Section 6.3.1 on page 61
SIP Num see Section 6.3.2 on page 62
Serv Addr see Section 6.3.3 on page 63
Serv Port see Section 6.3.4 on page 63
Reg Addr see Section 6.3.5 on page 64
Reg Port see Section 6.3.6 on page 65
Domain see Section 6.3.7 on page 65
User ID see Section 6.3.8 on page 66
Password see Section 6.3.9 on page 67
Password:
