Chapter 12 The Phone Book
V300 Series User’s Guide
134
Item This is the index number of the block list entry.
Number This is the block list entry’s phone number. Incoming calls from this
phone number are prevented from calling you.
Name This is the name associated with the blocked phone number, if
configured.
Modify Click the Edit icon to change this entry’s details.
Click the Delete icon to remove the entry from the block list. If you do
this for an entry not in the phonebook, the information cannot be
recovered.
Apply
Click this to save your settings.
Clear All Click this to remove all the entries from the block list. If you do this for
entries not in the phonebook, the information cannot be recovered.
Table 37 VoIP > Phone Book > Block List (continued)
LABEL DESCRIPTION
