![Zyxel V301-T1 [80/240] Clock alarm](/views2/1013116/page80/bg50.png)
Chapter 6 LCD Menus: Advanced
V300 Series User’s Guide
80
6.12 Clock Alarm
Use this menu to view the V300’s three internal clock alarm configurations.
Select Adv Setting > Clock Alarm. The following screen displays.
Figure 73 LCD Menu: Clock Alarm
Use the keys to cycle through the three clock alarms. Press to go back to
the previous menu when you are done.
To configure the clock alarms, you need to log into the Web Configurator. See
Chapter 13 on page 144 for more information.
6.13 Time Zone
Use this menu to choose the V300’s time zone of your location.
Select Adv Setting > Time Zone. The following screen displays.
Figure 74 LCD Menu: Time Zone
Use the keys to cycle through the time zones. Press to go back to the
previous menu when you are done.
Choose the time zone of your location. This will set the time difference between
your time zone and Greenwich Mean Time (GMT).
6.14 Date Format
Use this menu to select the date format that shows on the V300’s LCD.
Clock Alarm
1. 0:0 (off)
Time Zone
GMT 00:00
