Chapter 6 LCD Menus: Advanced
V300 Series User’s Guide
72
See the following sections for more information on each menu in this screen.
6.6.1 IP Address
Select Adv Setting > Static IP > IP Address. The following screen displays.
Figure 56 LCD Menu: IP Address
The number that displays is the static IP address currently configured on the
V300. Press to edit the static IP address, or press to return to the previous
screen.
6.6.1.1 IP Address - Edit
Press in the IP Address screen. The following screen displays.
Figure 57 LCD Menu: IP Address - Edit
Use PHONEBOOK to clear the previously-saved settings if any. Enter your static
IP address and press to save the change. Alternatively, press to return to the
previous screen.
Subnet Mask Select this to enter the subnet mask your V300 uses.
1st DNS Select this to enter the primary DNS (Domain Name System)
server’s IP address.
2nd DNS Select this to enter the secondary (backup) DNS server’s IP
address.
Table 14 LCD Menu: SIP Account Configuration
Static IP see Section 6.6 on page 71
IP Address see Section 6.6.1 on page
72
Gateway see Section 6.6.2 on page
73
Subnet Mask see Section 6.6.3 on page
73
1st and 2nd DNS
Servers
see Section 6.6.4 on page
74
Table 13 LCD Menu: Static IP
LABEL DESCRIPTION
2. IP Address
0.0.0.0
2. IP Address 1
0.0.0.0_
