Chapter 5 LCD Menus: Basic Settings
V300 Series User’s Guide
55
5.4.1 Volume Screen
When you select one of the options in the Volume Setting menu, a screen similar
to the following displays. This example uses the Speaker Volume screen.
Figure 18 LCD Menu: Volume Screen
Use the VOLUME keys to increase or decrease the volume. Press or to go
back to the previous menu when you are done.
5.5 The System Info Menu
The System Info menu allows you to quickly check some of your V300’s settings.
These settings are read-only.
Select MENU > System Info. The following screen displays.
Press
to enter the System Info menu and use the arrows to view the system
settings.
Figure 19 LCD Menu: System Info
The following table describes the labels in this menu.
Speaker Vol:-+
Menu Setting:
3. System Info
Table 9 LCD Menu: System Info
LABEL DESCRIPTION
IP Address This is the IP address currently assigned to the V300. This
displays 0.0.0.0 if DHCP is disabled.
Subnet Mask This is the subnet mask currently configured on the V300. This
displays 0.0.0.0 if DHCP is disabled.
Gateway This is the IP address of the device on the network your V300
uses to access the Internet. This displays 0.0.0.0 if DHCP is
disabled.
1st DNS This is the primary DNS (Domain Name System) server your
V300 uses. This displays 0.0.0.0 if DHCP is disabled.
2nd DNS This is the secondary (backup) DNS server your V300 uses. This
displays 0.0.0.0 if DHCP is disabled.
F/w Version This is the version number of the firmware currently running on
the V300. You can upload new firmware using the web
configurator.
