Chapter 6 LCD Menus: Advanced
V300 Series User’s Guide
70
6.4.4 Server Port
Select Adv > Auto Prov > Serv Port. The following screen displays.
Figure 51 LCD Menu: Serv Port
The default is ‘8080’. Press to change this.
If you make a mistake, use the PHONEBOOK key to delete your entry one number
at a time (you can use the asterix key [*] to enter periods). Press again to save
the port number.
6.4.5 Expire Time
Select Adv > Auto Prov > Expire Time. The following screen displays.
Figure 52 LCD Menu: Expire Time
The default is ‘3600’ seconds, or 60 minutes. Press to change this. The
maximum allowed is 259200 seconds, or 72 hours/3 days.
If you make a mistake, use the PHONEBOOK key to delete your entry one number
at a time. Press again to save the expire time.
6.4.6 Retry Time
Select Adv > Auto Prov > Retry Time. The following screen displays.
Figure 53 LCD Menu: Retry Time
The default and maximum is ‘1800’ seconds, or 30 minutes. Press to change
this. The minimum allowed is 1 second.
If you make a mistake, use the PHONEBOOK key to delete your entry one number
at a time. Press again to save the retry time.
4. Serv Port
8080
5. Expire Time
3600
6. Retry Time
1800
