Chapter 6 LCD Menus: Advanced
V300 Series User’s Guide
78
Use the VOLUME keys to increase or decrease the contrast. Press or to go
back to the previous menu when you are done.
6.10 Ring Setting
Select Adv Setting > Ring Setting. The following screen displays.
Figure 71 LCD Menu: Ring Type
Use the keys to cycle through the available ring types. Press or to go
back to the previous menu when you are done.
6.11 Flexworker Mode
Use this menu to turn Flexworker mode on or off.
The Flexworker feature allows you to “carry” your V300 settings with you when
you change locations but are still using a compatible V300 phone.
Select Adv Setting > Flexworker. The following screen displays.
Figure 72 LCD Menu: Flexworker Mode
Use the key to turn Flexworker mode either On or Off. Press to go back to the
previous menu when you are done.
6.11.1 Using Flexworker Mode
The Flexworker system lets a person use any V300 connected to an IP PBX that
supports auto-provisioning (such as the ZyXEL X6004) and retain its account-
specific settings.
All available V300 phones are suitable candidates as long as Flexworker is
activated in them. A person can log into any one of them. An unavailable IP phone
cannot be chosen as it is one that someone is already logged into it. It can only be
used once that person logs out.
Ring Type:
Chirp 0
Flexworker Mode
On
