Chapter 6 LCD Menus: Advanced
V300 Series User’s Guide
75
Select Adv Setting > PPPoE. The following screen displays.
Figure 64 LCD Menu: PPPoE
The following table describes the labels in this screen.
See the following sections for more information on each menu in this screen.
6.7.1 PPPoE Username
Select Adv Setting > PPPoE > Username. The following screen displays.
Figure 65 LCD Menu: PPPoE Username
Press to edit the PPPoE username, or press to return to the previous screen.
6.7.1.1 PPPoE Username - Edit
If you press in the Username screen, the following screen displays.
Figure 66 LCD Menu: PPPoE Username - Edit
1. PPPoE
Off
Table 15 LCD Menu: PPPoE
LABEL DESCRIPTION
PPPoE Use this to turn PPPoE on.
If DHCP or static IP is enabled, PPPoE will be disabled
automatically.
Username Enter your PPPoE username.
Password Enter your PPPoE password.
Table 16 LCD Menu: SIP Account Configuration
PPPoE see Section 6.7 on page 74
PPPoE Username see Section 6.7.1 on page
75
PPPoE Password see Section 6.7.2 on page
76
2. Username
2. Username 1
_
